84 CARRERA CABRIOLET

TECHNICAL SPECIFICATIONS

	Engine Design: Air cooled, lightweight aluminium alloy, horizontally opposed 6-cylinder, crossflow, hemispherical combustion chambers, 2 valves-per-cylinder, dual resonant induction, rear mounted.
	Displacement: 3.2 litre
	Horsepower (SAE net): 282 @ 6,100 rpm
	Torque: 250 lb-ft @ 5,250 rpm
	Compression ratio: 11.3:1
	Transmission: 5-speed manual transaxle or 4-speed Tiptronic dual function.
	Suspension, Front: Independent MacPherson struts, aluminum alloy lower control arms, coil srpings, stabilizer bar, negative steering roll radius.
	Suspension, Rear: Independent multi-link with LSA, self-stabilizing tow characteristics, stabilizer bar.
	Brake System: Power assisted, dual circuit, four-piston aluminum alloy fixed caliper, revised anti-lock braking system (ABS 5), vented cross-drilled discs, (front 11.97in./rear 11.77in.)
	Steering: Rack and pinion, force sensitive hydraulically assisted.
	Tires & Wheels: Std. Cast Alloy-Front: 7Jx17, 205/50ZR 17. Std. Cast-Alloy-Rear: 9Jx17, 255/40ZR 17.
	Acceleration: 0-60 mph in 5.7 seconds
	Top Track Speed: 149 mph (144 mph Tiptronic)
	Wheelbase: 89.4 in.
	Overall length: 167.7 in
	Track-Front/Rear: 55.3 in./56.9 in.
	Fuel Consumption City/Highway: 17/25
	Base Price: $63,750 (US)

STANDARD AND OPTIONAL EQUIPMENT

	Exterior Featurs 10-year limited anti-perforation corrosion warranty. 2-year, new vehicle limited warranty with unlimited mileage, including the Porsche roadside assistance program. 26-step paint process with 3 year limited warranty. Aerodynamic, redesigned front and rear bumpers. Unique modular poly-ellipsoid headlights with variable focus and washer system. Digital electronic fog lights integrated into the front apron. Larger, speed-dependent extendible rear spoiler. Redesigned third brake light. Full-power top on Cabriolet with automatic latching and unlatching. Electric sliding sunroof on coupe. Heated windshield washer nozzles. Electrically adjustable & heated outside rearview mirrors. Windshield antenna with interference suppression & signal amplifier. Wheel anti-theft device. Two-stage rear window defroster on coupe. Redesigned outside door handles, painted to match exterior color.
	Interior Features 2 + 2 seating. Automatic temperature control air conditioning with a new particle filtering system. Redesigned leather steering wheel.
	Safety Driver and front passenger ait bag supplemental restraint system. Interia reel front/rear, 3-point seat belts. Energy absorbing steering column. Brake pad wear indicators. Standard vented cross-bored disc brakes. ABS 5. Redesigned dual wiper system with variable delay.

CHANGES FOR THE 1996 MODEL YEAR

	Engine improvements VarioramTM induction system Internal engine and DME changes for more power and torque New exhause tips for all non-Turbo models 282 horsepower
	OBD II on-board diagnostic system for all models
	Optional 18 inch Turbo-look wheels
	Litronic gas discharge headlights (standard on Turbo, optional on all other models)
	Center brake light integrated in rear edge of roof (Coupe)
	Infrared interior anti-theft system (optional)
	Folding key integrated immobilizer system
	New radios
	Three new exterior colors
	One new interior color
